Diaphragm Compressor Gas Air Hydrogen 55kw Hydrogen High Working Efficiency Inlet 2mpa Discharge Flow 240nm3/h H2

CN¥17,312.46/pieces >=1 pieces
Price
Diaphragm Compressor Gas Air Hydrogen 55kw Hydrogen High Working Efficiency Inlet 2mpa Discharge Flow 240nm3/h H2
Features Gallery Product Description Request A Quote
Features
Specifications
Type: L-shape Diaphragm Compressor
Configuration: Other
Power Source: AC Power
Place Of Origin: Jiangsu, China
Brand Name: ChunMiao
Model Number: GL130
Voltage: Customized
Dimension(l*w*h): 6090x4236x2200
Warranty: 1 Year
Machinery Test Report: Not Available
Video Outgoing-inspection: Provided
Core Components: Other
Gas Type: Air
Weight (KG): 25000
Cooling Method: WATER COOLED
Highlight:

2mpa Hydrogen Diaphragm Compressor

,

240nm3/h Hydrogen Diaphragm Compressor

,

High Efficiency Diaphragm Compressor
Basic Infomation
Payment & Shipping Terms
Product Description
Diaphragm Compressor Gas Air Hydrogen 55kw Hydrogen High Working Efficiency Inlet 2mpa Discharge Flow 240nm3/h H2 0
Diaphragm Compressor Gas Air Hydrogen 55kw Hydrogen High Working Efficiency Inlet 2mpa Discharge Flow 240nm3/h H2 1
Diaphragm Compressor Gas Air Hydrogen 55kw Hydrogen High Working Efficiency Inlet 2mpa Discharge Flow 240nm3/h H2 2
Diaphragm Compressor Gas Air Hydrogen 55kw Hydrogen High Working Efficiency Inlet 2mpa Discharge Flow 240nm3/h H2 3
Diaphragm Compressor Gas Air Hydrogen 55kw Hydrogen High Working Efficiency Inlet 2mpa Discharge Flow 240nm3/h H2 4
Diaphragm Compressor Gas Air Hydrogen 55kw Hydrogen High Working Efficiency Inlet 2mpa Discharge Flow 240nm3/h H2 5
Diaphragm Compressor Gas Air Hydrogen 55kw Hydrogen High Working Efficiency Inlet 2mpa Discharge Flow 240nm3/h H2 6
Diaphragm Compressor Gas Air Hydrogen 55kw Hydrogen High Working Efficiency Inlet 2mpa Discharge Flow 240nm3/h H2 7
Diaphragm Compressor Gas Air Hydrogen 55kw Hydrogen High Working Efficiency Inlet 2mpa Discharge Flow 240nm3/h H2 8
Diaphragm Compressor Gas Air Hydrogen 55kw Hydrogen High Working Efficiency Inlet 2mpa Discharge Flow 240nm3/h H2 9
Diaphragm Compressor Gas Air Hydrogen 55kw Hydrogen High Working Efficiency Inlet 2mpa Discharge Flow 240nm3/h H2 10
Diaphragm Compressor Gas Air Hydrogen 55kw Hydrogen High Working Efficiency Inlet 2mpa Discharge Flow 240nm3/h H2 11
Diaphragm Compressor Gas Air Hydrogen 55kw Hydrogen High Working Efficiency Inlet 2mpa Discharge Flow 240nm3/h H2 12
Diaphragm Compressor Gas Air Hydrogen 55kw Hydrogen High Working Efficiency Inlet 2mpa Discharge Flow 240nm3/h H2 13
Diaphragm Compressor Gas Air Hydrogen 55kw Hydrogen High Working Efficiency Inlet 2mpa Discharge Flow 240nm3/h H2 14
Diaphragm Compressor Gas Air Hydrogen 55kw Hydrogen High Working Efficiency Inlet 2mpa Discharge Flow 240nm3/h H2 15
Diaphragm Compressor Gas Air Hydrogen 55kw Hydrogen High Working Efficiency Inlet 2mpa Discharge Flow 240nm3/h H2 16
Diaphragm Compressor Gas Air Hydrogen 55kw Hydrogen High Working Efficiency Inlet 2mpa Discharge Flow 240nm3/h H2 17
Diaphragm Compressor Gas Air Hydrogen 55kw Hydrogen High Working Efficiency Inlet 2mpa Discharge Flow 240nm3/h H2 18
Diaphragm Compressor Gas Air Hydrogen 55kw Hydrogen High Working Efficiency Inlet 2mpa Discharge Flow 240nm3/h H2 19
Diaphragm Compressor Gas Air Hydrogen 55kw Hydrogen High Working Efficiency Inlet 2mpa Discharge Flow 240nm3/h H2 20
Model
Volume flow
Nm³/h
Inlet pressure
MPa
Exhaust pressure
MPa
Revolutions
rpm
Motor power
kW
Cooling water flow
m³/h
Dimensions
(L×W×H)mm
Weight
ton
GL130/0/1.5
80-1400
0-1.2
1.5
400
18.5-37
≤3.2
2600×1630×1850
4
GL130/0.25/2.5
160-1300
0.25-2.0
2.5
400
22-37
≤3.2
2600×1630×1850
4
GL130/0.3/3
140-1200
0.3-2.5
3
400
30-37
≤3.2
2600×1630×1850
4
GL130/0/4
40-200
0-0.4
4
400
22-37
≤3.2
2600×1630×1850
4
GL130/0/6
30-160
0-0.45
6
400
22-37
≤3.2
2600×1630×1850
4
GL130/0.2/16
40-180
0.2-1.2
16
400
22-37
≤3.2
2600×1630×1850
4
GL130/0/20
40-45
0-0.012
20
400
22
≤1.8
2240×1490×1850
4
GL130/0.01/20
28-56
0.01-0.1
20
400
18.5-22
≤1.8
2240×1490×1850
4
GL130/0/20
20-80
0-0.2
20
400
15-37
≤3.2
2600×1630×1850
4
GL130/0.1/25
55-100
0.1-0.2
25
400
22-37
≤3.2
2600×1630×1850
4
GL130/2/80
40-150
2.0-6.0
80
400
22-37
≤3.2
2600×1630×1850
4

2H-shape Diaphragm compressor

High Purity Hydrogen H2 Helium Compressor
Support customization，Factory direct sales，Intelligent and efficient，ODM-OEM and more.
