Home /Products/Diaphragm Compressor/High Purity Explosive Proof Hydrogen Refueling Station Diaphragm Compressor For Lab

High Purity Explosive Proof Hydrogen Refueling Station Diaphragm Compressor For Lab

CN¥14,326.60/pieces >=1 pieces
Price
High Purity Explosive Proof Hydrogen Refueling Station Diaphragm Compressor For Lab
Features Gallery Product Description Request A Quote
Features
Specifications
Type: 2H-shape Diaphragm Compressor
Configuration: Other
Power Source: AC Power
Place Of Origin: Jiangsu, China
Brand Name: ChunMiao
Model Number: G2H130
Voltage: Customized
Dimension(l*w*h): 4200x2200x2300
Warranty: 1 Year
Machinery Test Report: Not Available
Video Outgoing-inspection: Provided
Core Components: Other
Gas Type: Air
Weight (KG): 9000
Cooling Method: WATER COOLED
Highlight:

Lab Diaphragm Compressor

,

Explosive Proof Diaphragm Compressor

,

Hydrogen Refueling Diaphragm Compressor
Basic Infomation
Payment & Shipping Terms
Product Description
High Purity Explosive Proof Hydrogen Refueling Station Diaphragm Compressor For Lab 0
High Purity Explosive Proof Hydrogen Refueling Station Diaphragm Compressor For Lab 1
High Purity Explosive Proof Hydrogen Refueling Station Diaphragm Compressor For Lab 2
High Purity Explosive Proof Hydrogen Refueling Station Diaphragm Compressor For Lab 3
High Purity Explosive Proof Hydrogen Refueling Station Diaphragm Compressor For Lab 4
High Purity Explosive Proof Hydrogen Refueling Station Diaphragm Compressor For Lab 5
High Purity Explosive Proof Hydrogen Refueling Station Diaphragm Compressor For Lab 6
High Purity Explosive Proof Hydrogen Refueling Station Diaphragm Compressor For Lab 7
High Purity Explosive Proof Hydrogen Refueling Station Diaphragm Compressor For Lab 8
High Purity Explosive Proof Hydrogen Refueling Station Diaphragm Compressor For Lab 9
High Purity Explosive Proof Hydrogen Refueling Station Diaphragm Compressor For Lab 10
High Purity Explosive Proof Hydrogen Refueling Station Diaphragm Compressor For Lab 11
High Purity Explosive Proof Hydrogen Refueling Station Diaphragm Compressor For Lab 12
High Purity Explosive Proof Hydrogen Refueling Station Diaphragm Compressor For Lab 13
High Purity Explosive Proof Hydrogen Refueling Station Diaphragm Compressor For Lab 14
High Purity Explosive Proof Hydrogen Refueling Station Diaphragm Compressor For Lab 15
High Purity Explosive Proof Hydrogen Refueling Station Diaphragm Compressor For Lab 16
High Purity Explosive Proof Hydrogen Refueling Station Diaphragm Compressor For Lab 17
High Purity Explosive Proof Hydrogen Refueling Station Diaphragm Compressor For Lab 18
High Purity Explosive Proof Hydrogen Refueling Station Diaphragm Compressor For Lab 19
High Purity Explosive Proof Hydrogen Refueling Station Diaphragm Compressor For Lab 20
Model
Volume flow
Nm³/h
Inlet pressure
MPa
Exhaust pressure
MPa
Revolutions
rpm
Motor power
kW
Cooling water flow
m³/h
Dimensions
(L×W×H)mm
Weight
ton
G2H130/0.1/5
200-300
0.1-0.2
5
360
75
≤6.0
4200×2200×2300
9
G2H130/0/1.5
160-2800
0-1.2
1.5
360
45-75
≤6.0
3500×2200×1900
8
G2H130/0/3
70-300
0-0.3
3
360
45-55
≤4.5
3500×2200×1900
8
G2H130/0/6
60-320
0-0.45
6
360
55
≤4.5
3500×2200×1900
8
G2H130/0.2/6
100-540
0.2-1.3
6
360
55
≤4.5
3500×2200×1900
8
G2H130/0.35/20
90-320
0.35-1.4
20
360
55
≤4.5
3500×2200×1900
8
G2H130/0.2/25
100-220
0.2-0.55
25
360
75
≤6.0
3500×2200×1900
8

2H-shape Diaphragm compressor

High Purity Explosive Proof Hydrogen Refueling Station Diaphragm Compressor
Support customization，Factory direct sales，Intelligent and efficient，ODM-OEM and more.
For more information, please contact us.
