Home /Products/Diaphragm Hydrogen Compressor/Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium

Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium

CN¥19,764.22/pieces >=1 pieces
Price
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium
Features Gallery Product Description Request A Quote
Features
Specifications
Type: Z-shape Diaphragm Compressor
Configuration: Other
Power Source: AC Power
Place Of Origin: Jiangsu, China
Brand Name: ChunMiao
Model Number: GZ130
Voltage: Customized
Dimension(l*w*h): 6090x4236x2200
Warranty: 1 Year
Machinery Test Report: Not Available
Video Outgoing-inspection: Provided
Core Components: Other
Gas Type: Air
Weight (KG): 25000
Cooling Method: WATER COOLED
Highlight:

Helium Diaphragm Compressor

,

Nitrogen Diaphragm Compressor
Basic Infomation
Payment & Shipping Terms
Product Description
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 0
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 1
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 2
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 3
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 4
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 5
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 6
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 7
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 8
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 9
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 10
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 11
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 12
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 13
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 14
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 15
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 16
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 17
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 18
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 19
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 20
Model
Volume flow
Nm³/h
Inlet pressure
MPa
Exhaust pressure
MPa
Revolutions
rpm
Motor power
kW
Cooling water flow
m³/h
Dimensions
(L×W×H)mm
Weight
ton
GZ130/0/1.5
40-700
0-1.2
1.5
400
15-18.5
≤1.4
1800×1290×1900
2.6
GZ130/0/2
28-600
0-1.5
1.0-2.0
400
15-18.5
≤1.4
1800×1290×1900
2.6
GZ130/0.3/3
70-600
0.3-2.5
3
400
15-18.5
≤1.4
1800×1290×1900
2.6
GZ130/0.4/4
70-700
0.4-3.5
4
400
15-18.5
≤1.4
1800×1290×1900
2.6
GZ130/0.5/5
70-700
0.5-4.5
5
400
15-18.5
≤1.4
1800×1290×1900
2.6
GZ130/0.7/7
60-650
0.7-6.5
7
400
15-18.5
≤1.4
1800×1290×1900
2.6
GZ130/1.2/16
46-650
1.2-14.0
16
400
15-18.5
≤1.4
1800×1290×1900
2.6
GZ130/1.3/20
40-650
1.3-16.0
20
400
15-18.5
≤1.4
1800×1290×1900
2.6
GZ130/5/45
50-325
5.0-20.0
45
430
<22
≤1.8
2100×1500×1900
3
GZ130/8/80
36-600
8.0-70.0
80
400
22
≤1.8
2100×1500×1900
3.5

2H-shape Diaphragm compressor

High Purity Hydrogen H2 Helium Compressor
Support customization，Factory direct sales，Intelligent and efficient，ODM-OEM and more.
For more information, please contact us.
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 21
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 22
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 23
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 24
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 25
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 26
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 27
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 28
Diaphragm Compressor Gas Air Hydrogen Diaphragm Compressors High Pressure 0.6mpa Gd Type For Nitrogen / Helium 29
