Home /Products/Diaphragm Air Compressor/Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane

Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane

CN¥16,389.64/pieces >=1 pieces
Price
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane
Features Gallery Product Description Request A Quote
Features
Specifications
Type: Z-shape Diaphragm Compressor
Configuration: Other
Power Source: AC Power
Place Of Origin: Jiangsu, China
Brand Name: ChunMiao
Model Number: GZ130
Voltage: Customized
Dimension(l*w*h): 4200x2200x2300
Warranty: 1 Year
Machinery Test Report: Not Available
Video Outgoing-inspection: Provided
Core Components: Other
Gas Type: Air
Weight (KG): 9000
Cooling Method: WATER COOLED
Highlight:

Membrane Air Compressor

,

Hydrogen Gas Piston Screw Type Compressor

,

Rotary Screw Type Air Compressor
Basic Infomation
Payment & Shipping Terms
Product Description
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 0
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 1
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 2
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 3
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 4
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 5
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 6
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 7
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 8
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 9
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 10
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 11
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 12
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 13
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 14
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 15
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 16
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 17
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 18
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 19
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 20
Model
Volume flow
Nm³/h
Inlet pressure
MPa
Exhaust pressure
MPa
Revolutions
rpm
Motor power
kW
Cooling water flow
m³/h
Dimensions
(L×W×H)mm
Weight
ton
GZ130/0/1.5
40-700
0-1.2
1.5
400
15-18.5
≤1.4
1800×1290×1900
2.6
GZ130/0/2
28-600
0-1.5
1.0-2.0
400
15-18.5
≤1.4
1800×1290×1900
2.6
GZ130/0.3/3
70-600
0.3-2.5
3
400
15-18.5
≤1.4
1800×1290×1900
2.6
GZ130/0.4/4
70-700
0.4-3.5
4
400
15-18.5
≤1.4
1800×1290×1900
2.6
GZ130/0.5/5
70-700
0.5-4.5
5
400
15-18.5
≤1.4
1800×1290×1900
2.6
GZ130/0.7/7
60-650
0.7-6.5
7
400
15-18.5
≤1.4
1800×1290×1900
2.6
GZ130/1.2/16
46-650
1.2-14.0
16
400
15-18.5
≤1.4
1800×1290×1900
2.6
GZ130/1.3/20
40-650
1.3-16.0
20
400
15-18.5
≤1.4
1800×1290×1900
2.6
GZ130/5/45
50-325
5.0-20.0
45
430
<22
≤1.8
2100×1500×1900
3
GZ130/8/80
36-600
8.0-70.0
80
400
22
≤1.8
2100×1500×1900
3.5

2H-shape Diaphragm compressor

High Purity Explosive Proof Hydrogen Refueling Station Diaphragm Compressor
Support customization，Factory direct sales，Intelligent and efficient，ODM-OEM and more.
For more information, please contact us.
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 21
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 22
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 23
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 24
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 25
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 26
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 27
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 28
Diaphragm Compressor Gas Air Hydrogen Gas Piston Screw Type Pressure Switch Highly Rotary Membrane 29
