Home /Products/High Pressure Diaphragm Compressor/Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station

Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station

CN¥18,538.63/pieces >=1 pieces
Price
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station
Features Gallery Product Description Request A Quote
Features
Specifications
Type: 2H-shape Diaphragm Compressor
Configuration: Other
Power Source: AC Power
Place Of Origin: Jiangsu, China
Brand Name: ChunMiao
Model Number: G2H130
Voltage: Customized
Dimension(l*w*h): 4200x2200x2300
Warranty: 1 Year
Machinery Test Report: Not Available
Video Outgoing-inspection: Provided
Core Components: Other
Gas Type: Air
Weight (KG): 9000
Cooling Method: WATER COOLED
Highlight:

Air Diaphragm Compressor Explosive Proof

,

High Pressure Hydrogen Compressor

,

High Purity Hydrogen Compressor
Basic Infomation
Payment & Shipping Terms
Product Description
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 0
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 1
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 2
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 3
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 4
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 5
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 6
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 7
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 8
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 9
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 10
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 11
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 12
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 13
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 14
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 15
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 16
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 17
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 18
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 19
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 20
Model
Volume flow
Nm³/h
Inlet pressure
MPa
Exhaust pressure
MPa
Revolutions
rpm
Motor power
kW
Cooling water flow
m³/h
Dimensions
(L×W×H)mm
Weight
ton
GV130/0/2
56-1200
0-1.5
1.0-2.0
400
22-37
≤3.2
2600×1630×1850
4
GV130/0/6
30-170
0-0.5
6
400
22-37
≤3.2
2600×1630×1850
4
GV130/0/7
30-130
0-0.35
7
400
22-37
≤3.2
2600×1630×1850
4
GV130/0/16
30-60
0-0.1
16
400
18.5-22
≤1.8
2240×1490×1850
4
GV130/0/20
28-56
0-0.1
20
400
18.5-22
≤1.8
2240×1490×1850
4
GV130/0.1/20
37-85
0.1-0.35
20
400
22-37
≤3.2
2600×1630×1850
4
GV130/0.2/20
45-100
0.2-0.65
20
400
22-37
≤3.2
2600×1630×1850
4
GV130/0.3/20
20-120
0.3-0.8
20
400
22-37
≤3.2
2600×1630×1850
4
GV130/0.35/20
45-160
0.35-1.4
20
400
22-37
≤3.2
2600×1630×1850
4
GV130/0.4/20
40-190
0.4-2.0
20
400
22-37
≤3.2
2600×1630×1850
4
GV130/1.3/20
80-1000
1.3-11.0
20
400
22-37
≤3.2
2600×1630×1850
4
GV130/0.1/25
37-60
0.1-0.25
25
400
22-37
≤3.2
2600×1630×1850
4
GV130/0.25/25
30-90
0.25-1.0
25
400
22-37
≤3.2
2600×1630×1850
4
GV130/0.35/25
36-120
0.35-1.3
25
400
22-37
≤3.2
2600×1630×1850
4
GV130/0.6/25
36-250
0.6-4.5
25
400
22-37
≤3.2
2600×1630×1850
4
GV130/0.4/35
34-90
0.4-1
35
400
22-37
≤3.2
2600×1630×1850
4
GV130/0.65/45
32-120
0.65-2.4
45
400
22-37
≤3.2
2600×1630×1850
4

2H-shape Diaphragm compressor

High Purity Explosive Proof Hydrogen Refueling Station Diaphragm Compressor
Support customization，Factory direct sales，Intelligent and efficient，ODM-OEM and more.
For more information, please contact us.
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 21
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 22
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 23
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 24
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 25
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 26
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 27
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 28
Diaphragm Compressor Gas Air Compressors Hydrogen High Pressure High Purity Explosive Proof Hydrogen Refueling Station 29
